This ultra-compact IoT core module PCB is engineered for embedded development and IoT applications, featuring a space-saving form factor and essential connectivity features. Built on a high-quality black FR-4 substrate with gold-plated pin headers, it integrates a Micro SD card slot for data storage, advanced power management ICs, and signal conditioning components to ensure stable performance in battery-powered devices.
Designed for easy integration into breadboards and custom circuits, the module’s gold-plated pins provide reliable electrical contact and corrosion resistance, while the dense SMD layout maximizes functionality in a minimal footprint. Ideal for prototyping and mass production, this PCB module supports seamless data logging, wireless communication, and edge computing for smart sensors, wearables, and industrial IoT devices. Compliant with RoHS standards, it delivers long-term reliability for diverse embedded projects.
| Place of Origin | China (Mainland) |
| Brand Name | Customizable (OEM/ODM supported) |
| Model Number | IoT-MOD-PCB-001 (customizable) |
| Certification | RoHS, CE |
| Base Material | FR-4 Glass Epoxy (Black Solder Mask) |
| Layers | 4 layers (high-density design) |
| Board Thickness | 1.0mm / 1.6mm (customizable) |
| Surface Finish | ENIG (gold-plated pins) |
| Form Factor | Compact module (breadboard-compatible) |
| Key Features | Micro SD card slot, gold-plated pin headers, power management ICs |
| Power Input | 3.3V / 5V DC (customizable) |
| Operating Temperature | -20°C ~ +70°C |
| Assembly Type | High-precision SMT assembly |
· IoT sensor nodes & data logging devices
· Wearable electronics & portable smart devices
· Embedded prototyping & development boards
· Industrial monitoring & edge computing modules
· Battery-powered smart home devices
1. Ultra-Compact Size: Miniature form factor ideal for space-constrained embedded applications.
2. Reliable Connectivity: Gold-plated pin headers ensure stable contact and long service life.
3. Data Storage: Integrated Micro SD card slot supports local data logging and expansion.
4. Efficient Power Management: Onboard power ICs optimize energy usage for battery-powered devices.
5. Easy Integration: Breadboard-compatible design simplifies prototyping and system integration.
Q: Does this module support wireless communication?
A: The base design can be customized to integrate Wi-Fi/Bluetooth modules, depending on your project requirements.
Q: What is the maximum storage capacity supported by the Micro SD slot?
A: It supports up to 32GB (or higher, depending on firmware configuration) for data logging and storage.
Q: Can the pinout and component layout be customized?
A: Yes, we offer full customization of pinout, component selection, and form factor to match your project needs.
