This high-performance industrial motor control PCB assembly is engineered for miniature drive systems and precision motion control applications. Built on a robust green FR-4 substrate, it integrates a dedicated microcontroller (MCU), advanced power management circuits, and high-current MOSFET drivers to deliver efficient and reliable motor control.
The board features a compact form factor with clearly labeled terminal blocks for motor phase connections, power input, and signal interfaces, alongside an LCD interface for real-time parameter monitoring and configuration. Precision SMD component placement and optimized trace routing ensure stable signal transmission and efficient heat dissipation, making it ideal for industrial automation, small-scale robotics, and precision actuator control systems.
Compliant with IPC Class 2/3 and RoHS standards, this PCB assembly undergoes rigorous quality testing to guarantee long-term reliability in demanding industrial environments. It provides a turnkey solution for motor drive development, reducing time-to-market and simplifying system integration.
| Place of Origin | China (Mainland) |
| Brand Name | Customizable (OEM/ODM supported) |
| Model Number | MOTOR-DRV-PCB-001 (customizable) |
| Certification | ISO9001, RoHS, IPC Class 2/3 |
| Base Material | FR-4 Glass Epoxy |
| Layers | 4 layers (high-density design) |
| Board Thickness | 1.6mm |
| Surface Finish | ENIG / HASL (lead-free) |
| Solder Mask | Green |
| Core Controller | Industrial-grade 32-bit MCU |
| Power Drivers | High-current MOSFETs (customizable current rating) |
| Power Input | 12V/24V DC (customizable) |
| Interfaces | Motor phase terminals, LCD interface, signal pin headers, power connectors |
| Operating Temperature | -40°C ~ +85°C (industrial grade) |
| Assembly Type | SMT + Through-Hole mixed assembly |
· Industrial miniature motor drive systems
· Precision robotics & actuator control
· Small-scale automation equipment
· Medical device motor control modules
· Automotive auxiliary motor controllers
1. Precise Control: Dedicated MCU and power driver design delivers accurate speed and torque control for miniature motors.
2. Efficient Power Management: Integrated DC-DC conversion and filtering circuits ensure stable power supply and low energy consumption.
3. User-Friendly Interface: LCD and terminal block connections simplify parameter monitoring, configuration, and system wiring.
4. Robust Reliability: Industrial-grade components and thermal design guarantee stable operation in harsh environments.
5. Turnkey Solution: Fully assembled PCB reduces development time and enables quick integration into end products.
Q: What types of motors can this PCB control?
A: It is designed for DC brush motors, stepper motors, and small BLDC motors (customizable for specific motor types).
Q: What is the maximum continuous current the power drivers can handle?
A: The standard design supports up to 10A continuous current (customizable for higher current requirements).
Q: Can the firmware for the MCU be customized?
A: Yes, we offer full firmware development and customization services to match specific motor control algorithms.
