This versatile industrial control development PCB is engineered for smart automation and IoT applications, featuring a robust black solder mask substrate and rich interface integration. Built around a high-performance 32-bit MCU, it combines wired connectivity (USB, LAN) and wireless communication (WiFi) to support seamless data exchange and remote control.
The board includes multiple relay output terminals, terminal block interfaces, and physical control buttons (STOP/GO), enabling direct integration with actuators, sensors, and industrial equipment. Precision power management circuits (including DC-DC converters) ensure stable operation under varying load conditions, while the compact form factor simplifies installation into custom enclosures.
Compliant with RoHS and industrial quality standards, this development board provides a turnkey platform for rapid prototyping of smart factory systems, building automation, and IoT gateways, reducing time-to-market for industrial control solutions.
| Place of Origin | China (Mainland) |
| Brand Name | Customizable (OEM/ODM supported) |
| Model Number | IND-DEV-BOARD-001 (customizable) |
| Certification | RoHS, CE, IPC Class 2/3 |
| Base Material | FR-4 Glass Epoxy |
| Layers | 4-6 layers (high-density design) |
| Board Thickness | 1.6mm |
| Surface Finish | ENIG / HASL (lead-free) |
| Solder Mask | Black |
| Core Controller | 32-bit industrial-grade MCU |
| Connectivity | USB, LAN (Ethernet), WiFi, Infrared (INFRARED) |
| Control Interfaces | Relay terminals, terminal blocks, physical buttons (STOP/GO) |
| Power Input | DC power jack (12V/24V customizable) |
| Operating Temperature | -20°C ~ +70°C |
| Assembly Type | SMT + Through-Hole mixed assembly |
· Smart factory automation & PLC development
· Building control systems (lighting, HVAC, access control)
· IoT gateways & remote monitoring devices
· Industrial sensor data acquisition & processing
· Smart home control hubs & energy management systems
1. Rich Connectivity: Combines USB/LAN/WiFi/Infrared interfaces for flexible wired/wireless communication.
2. Integrated Control: Onboard relays and terminal blocks enable direct connection to industrial actuators and loads.
3. User-Friendly Operation: Physical STOP/GO buttons and status LEDs for intuitive manual control and system diagnostics.
4. Stable Power Supply: Precision DC-DC conversion circuits ensure reliable power delivery for continuous operation.
5. Rapid Prototyping: Turnkey design reduces development time for industrial control and IoT applications
Q: Does this board support remote control via WiFi?
A: Yes, the integrated WiFi module enables remote monitoring and control via mobile app or web interface.
Q: What is the maximum load current for the relay outputs?
A: The standard design supports up to 5A/250V AC per relay channel (customizable for higher current requirements).
Q: Can I program the MCU using the USB interface?
A: Yes, the USB port supports firmware programming and serial communication with the core MCU.
