This high-density industrial control PCB module is engineered for embedded systems and industrial automation, featuring the DM368ZCE application-specific integrated circuit (ASIC) for high-performance processing. Built on a premium FR-4 substrate with green solder mask, the module integrates dense SMD components, high-speed signal traces, and robust power management circuits to ensure stable operation in harsh industrial environments.
Designed with a compact form factor, the PCB supports seamless integration into space-constrained devices such as industrial controllers, data acquisition (DAQ) units, and embedded communication gateways. The integrated memory and power regulation circuitry minimize external component count, while precision trace routing guarantees signal integrity for high-speed data transmission.
Compliant with IPC Class 2/3 and RoHS standards, the module undergoes rigorous quality testing to deliver long-term reliability. Whether for prototype development or mass production, this high-density control PCB provides a reliable, cost-effective solution for advanced embedded control and data processing applications.
| Place of Origin | China (Mainland) |
| Brand Name | Customizable (OEM/ODM supported) |
| Model Number | EMB-PCB-DM368-001 (customizable) |
| Certification | ISO9001, RoHS, IPC Class 2/3 |
| Base Material | FR-4 Glass Epoxy (High Tg optional) |
| Layers | 4-6 layers (high-precision) |
| Board Thickness | 1.6mm (customizable) |
| Surface Finish | ENIG / HASL (Lead-free) |
| Solder Mask | Green (standard) |
| Core Processor | DM368ZCE (TI/ST configurable) |
| Memory | Integrated Flash + SRAM (expandable) |
| Key Interfaces | 2.54mm Pin Headers, Power Input, Signal Ports |
| Power Management | Onboard DC-DC Converter (5V/12V input) |
| Operating Temperature | -40°C ~ +85°C (industrial grade) |
| Minimum Trace Width | 0.1mm (high-density design) |
· Industrial automation controllers & PLCs
· Embedded data acquisition (DAQ) systems
· IoT gateways & wireless communication modules
· Medical equipment control boards
· Automotive electronics & vehicle control units
1. High Integration: Dense component layout minimizes system size, ideal for compact embedded devices.
2. Processing Power: DM368ZCE core chip delivers high computational efficiency for real-time control tasks.
3. Signal Integrity: Precision PCB design reduces crosstalk, supporting high-speed data transmission and low noise.
4. Environmental Robustness: Industrial-grade components and FR-4 substrate ensure reliable operation in wide temperature ranges.
5. Flexible Design: Customizable interface and memory expansion options adapt to diverse project requirements.
Q: Does this PCB support software customization for the DM368ZCE chip?
A: Yes, we offer full firmware and hardware customization, including driver development and system integration for the core processor.
Q: What is the typical lead time for mass production?
A: Mass production lead time is approximately 15-25 days; prototype assembly is available within 7-10 days.
Q: Can this module be powered by a 12V DC input?
A: Yes, the onboard DC-DC converter supports 5V-12V wide voltage input, ensuring compatibility with standard industrial power supplies.
