This smart LED digital display PCB module integrates high-brightness LED dot matrix, WiFi connectivity, and RF wireless control, designed for real-time timing, counting, and scoreboard applications. Built on a black solder mask substrate, it features a 6-digit LED array, WiFi module, and RF antenna for remote data update and wireless synchronization.
With precise LED driving circuit and stable wireless communication, this module delivers clear visibility in various lighting conditions and supports remote configuration via mobile app or web interface. It is ideal for sports scoreboards, event timers, industrial counters, and smart signage, offering a reliable and flexible solution for digital display needs.
| Place of Origin | China (Mainland) |
| Brand Name | Customizable (OEM/ODM supported) |
| Model Number | LED-DISPLAY-WIFI-006 (customizable) |
| Certification | RoHS, CE, FCC |
| Base Material | FR-4 Glass Epoxy (Black Solder Mask) |
| Layers | 2-4 layers (customizable) |
| Board Thickness | 1.6mm |
| Surface Finish | ENIG / HASL |
| Display Type | 6-digit LED Dot Matrix (White LEDs) |
| Connectivity | WiFi 2.4GHz + RF Wireless |
| Antenna | External RF Antenna + Onboard WiFi Antenna |
| Input Voltage | 5V DC (customizable) |
| Operating Temperature | -20°C ~ +60°C |
| Brightness | Adjustable via software |
· Sports scoreboards & event timing systems
· Industrial production counters & digital signage
· Smart home clocks & public information displays
· Race timers & competition scoring devices
1. Wireless Control: WiFi + RF dual connectivity for remote data update and synchronization.
2. High Visibility: Bright white LED dot matrix ensures clear readability in bright and low-light environments.
3. Flexible Configuration: Supports custom digit patterns, timing modes, and brightness adjustment via software.
4. Compact Design: Integrated module design reduces system complexity and simplifies installation.
5. Reliable Performance: Stable circuit design and high-quality components guarantee long-term operation.
Q: Can this module be controlled via a mobile app?
A: Yes, it supports WiFi connection to a mobile app or web dashboard for real-time data editing and remote control.
Q: What is the maximum number of digits that can be displayed?
A: The standard design features 6 digits, and we can customize the display length (e.g., 4-digit, 8-digit) to meet specific needs.
Q: Is the LED brightness adjustable?
A: Yes, the brightness can be adjusted via software commands or physical buttons to adapt to different ambient light conditions.
